Fork of kantiankant/swindle with respect, itself a fork of dwl

Tip

Want a status bar? vindle draws none, but any layer shell bar works and the tiling area avoids it. See External Bars

Contents

• Quick Start
• What vindle is
• What changed on top of swindle
• Features
• Screenshots
• Installation
• Usage
• Key Bindings
• Configuration
• Window Rules
• Monitors
• External Bars
• How It Works
• Contributing
• Related

---

Quick Start

git clone https://github.com/tinyopsec/vindle
cd vindle
make && sudo make install
cp /etc/vindle/config.lua ~/.config/vindle/config.lua
vindle

Note

The default terminal is foot and the default launcher is fuzzel. Change them in your config before starting if you use something else (see Configuration)

vindle needs XDG_RUNTIME_DIR for the Wayland socket. On a seat it is set already; with a bare flow, export it first

---

What vindle is

vindle manages windows and input on Wayland and nothing else. One tiling layout (dwindle) plus floating, 9 tags as a bitmask, predictable focus, a double border inherited from the swindle lineage and kept. No bar, no widgets, no wallpaper, no animations, no themes. External programs cover the rest: foot, fuzzel, waybar, swaybg.

It is written to be read. About 7700 lines of C, headers and Lua in total, the compositor itself about 3900. If you spare an evening you will know where everything lives.

---

What changed on top of swindle

Everything below is user visible, no refactors for beauty:

• Comfortable standard keymap (hjkl focus, t tile, f float, g gaps)
• us first and ru second out of the box with Alt+Shift toggle (I am Kazakh, Russian is near native, Latin must work on first boot); one line in input.layout changes the order, binds work in every layout
• Dwindle honors the monitor mfact instead of always splitting evenly
• Mouse drag floats a tiled window in place and carries it across tags
• Unknown config keys print a warning instead of failing silently
• Monitor fields reapply on config save, no restart dance for them
• smsg client tool on the frozen dwl-ipc protocol
• Wayland native defaults: foot, fuzzel, waybar, swaybg
• A real man page (man vindle)

---

Features

Category	Details
Layouts	Dwindle (binary split, honors mfact) and floating
Workspaces	9 tags via bitmasks; windows may carry multiple tags
Mouse support	Move, resize, toggle floating via modifier plus button; a tiled window floats in place at its current size; carry a dragged window to another tag with the tag keys
Gaps	Configurable gaps with smart_gaps; toggle at run time with Mod+g
Borders	Double ring: inner plus outer widths and colors for normal, focus and urgent states. The two rings plus the gap read as one calm frame, my favorite part of the look
Fullscreen	Toggle via keybind or client request
Urgent hints	Activation requests mark windows urgent instead of stealing focus
Dialogs	Dialog windows and fixed size windows float automatically
Layer shell	Bars and panels reserve space; tiling avoids it
XWayland	Optional at build time (XWAYLAND in config.mk)
Keyboard	us first, ru second with Alt+Shift toggle (my native pair, changeable in one line); layout independent binds with key repeat
Hot reload	Config watcher reapplies values on save; input options still need a restart
IPC	Frozen dwl-ipc surface plus smsg client tool
Compilation	Zero warnings under -std=c11 -Wall -Wextra

---

Screenshots

This is my screenshot, vindle on Void Linux

---

Installation

Requirements

Dependency	Purpose	Note
wlroots 0.20	Compositor backend	Pinned major, compiled with libinput
wayland	Protocols	Server side
libinput	Pointer and touchpad config
xkbcommon	Keyboard layouts
lua5.4	Config file	Frozen, no upgrades
wayland-protocols, wayland-scanner, pkg-config	Build time only
xcb, xcb-icccm	XWayland build flag only

Install these with their development packages, then build. Tested on Void Linux.

From Source

git clone --depth 1 https://github.com/tinyopsec/vindle
cd vindle
make
sudo make install   # installs to /usr/local/bin/vindle, config to /etc/vindle, man page to share/man/man1

Change PREFIX in config.mk to install elsewhere. To stage the install (packaging), use make DESTDIR=/tmp/stage install. Downstream packaging is out of scope for this repo on purpose: the portable Makefile covers all targets.

BSD notes (best effort, community tested)

Linux is the first class target. BSD builds on a best effort basis with no promises.

gmake LUA_PKG=lua-5.4
sudo gmake ETCDIR=/usr/local/etc/vindle install

Start from a TTY, not from inside X11 (unset DISPLAY or set WLR_BACKENDS to pick the DRM backend). Seat access is required: enable seatd, join the video group. If no user config exists, the installed default is used directly.

Uninstall

sudo make uninstall

---

Usage

Starting vindle

From a TTY:

vindle

With an explicit config or a startup command:

vindle -c ~/.config/vindle/config.lua
vindle -s "waybar"

vindle -v prints the version. vindle -d enables debug logging.

Display Managers

For display managers:

# /usr/share/wayland-sessions/vindle.desktop
[Desktop Entry]
Name=vindle
Comment=Minimal tiling Wayland compositor
Exec=vindle
Type=Application

Terminal and Launcher

Defaults in example/config.lua:

{ mods = {"logo"}, key = "Return", action = "spawn", args = {"foot"} },
{ mods = {"logo"}, key = "d",      action = "spawn", args = {"fuzzel"} },

Use any Wayland native pair instead, for example foot plus bemenu or alacritty plus fuzzel.

Important

Copy /etc/vindle/config.lua to ~/.config/vindle/config.lua and edit the copy. Reinstalls overwrite /etc/vindle

---

Key Bindings

The default modifier is Super (Win).

Windows and Layouts

Key	Action
Mod + Return	Spawn terminal (foot)
Mod + d	Spawn launcher (fuzzel)
Mod + q	Kill focused window
Mod + Shift + e	Quit vindle
Mod + h	Focus left
Mod + j	Focus down
Mod + k	Focus up
Mod + l	Focus right
Mod + Tab	Toggle to the previously viewed tag set
Mod + t	Dwindle layout
Mod + f	Floating layout
Mod + F11	Toggle fullscreen
Mod + Shift + Space	Toggle floating for focused window
Mod + 0	View all tags
Mod + Shift + 0	Assign focused window to all tags
Mod + g	Toggle gaps
Mod + Shift + H/J/K/L	Swap with the neighbor in that direction
Mod + comma/period	Focus monitor left/right
Mod + Shift + less/greater	Send focused window to monitor left/right

Tags

Key	Action
Mod + 1-9	Switch to tag
Mod + Ctrl + 1-9	Toggle tag view (show alongside current)
Mod + Shift + 1-9	Move focused window to tag
Mod + Ctrl + Shift + 1-9	Toggle tag assignment on focused window

Mouse (modifier held over a client window)

Button	Action
Mod + Left	Move window (tiled windows float in place)
Mod + Middle	Toggle floating
Mod + Right	Resize window

While dragging, tag and view keys apply to the dragged window, so it travels to the new tag with you.

All bindings live in keybinds and buttons in the Lua config.

---

Configuration

The chain is example/config.lua (repo) to /etc/vindle/config.lua (installed default) to ~/.config/vindle/config.lua (yours). The compositor watches your file and reloads on save.

Section	Holds
Top level	sloppy_focus, bypass_surface_visibility, log_level
appearance	Inner and outer border widths and colors (normal, focus, urgent), gaps, smart_gaps, root and fullscreen colors
input	Repeat rate and delay, libinput options, layout/variant/options for XKB
rules	app_id, title, tags, floating, monitor per window
monitors	name, mfact, nmaster, scale, layout, transform, x, y per output
keybinds, buttons	Mods plus key or button plus action plus args
autostart	Plain shell commands, run in order once the socket is live

Reload notes:

• Appearance, rules, binds, autostart list and monitor mfact apply on save without a restart
• Input options (repeat, libinput, layout) apply at startup only
• Misspelled keys print unknown key warnings to standard error. The session keeps running

---

Window Rules

rules = {
    { app_id = "Gimp",    floating = true,  monitor = -1 },
    { app_id = "MPlayer", floating = true,  monitor = -1 },
}

Empty app_id or title matches anything. monitor -1 means current. Dialogs and fixed size windows float even without a rule.

---

Monitors

monitors = {
    { name = nil, mfact = 0.5, nmaster = 1, scale = 1.0,
      layout = "dwindle", x = -1, y = -1 },
}

First match wins; empty name matches any output. mfact is the first child share of every dwindle split (0.5 splits evenly, 0.7 was tried live and looked ugly so 0.5 stays). nmaster is accepted but reserved by the dwindle layout. x and y of -1 mean automatic placement

---

External Bars

vindle has no bar and never will: drawing widgets is outside its scope. It cooperates with layer shell bars, so the bar reserves its edge and tiling uses what is left.

Minimal waybar autostart (~/.config/vindle/config.lua):

autostart = {
    "dbus-update-activation-environment WAYLAND_DISPLAY XDG_SESSION_TYPE XDG_CURRENT_DESKTOP",
    "waybar",
}

Start wallpaper the same way (swaybg -i ~/wall.png -m fill), since the compositor manages no wallpaper itself.

---

How It Works

vindle renders through the wlroots scene graph. Each window owns a scene tree with its surface plus eight border rectangles (four inner, four outer). Tiling writes geometry into a per tag binary tree and the tree is walked top down with integer arithmetic, so there is no pixel drift. Every split divides the parent in the mfact share; wider parents split left and right, taller ones top and bottom.

Tags are bitmasks. Each client carries a tag bitmask and the active view is a bitmask. A client is visible when the bitwise AND of its tags and the current view is nonzero.

Focus is explicit and predictable: the focused client leads the focus stack, tag switches refocus the top visible client, urgency never steals focus, fullscreen is tracked per monitor. The focused window is the dwindle insertion anchor, so new windows split what you look at.

State leaves the compositor two ways: human readable stdout lines (tags, titles, layouts per output, same shape as dwl) and the frozen dwl-ipc protocol consumed by smsg. The ext-workspace protocol publishes one workspace object per tag per monitor for panels that speak it.

It is hard to explain in words, but you can grasp the entire code structure if you spend an evening reading the code. I use this compositor daily, so rough edges get fixed fast.

---

Contributing

Found a bug or a rough edge. Open an issue, I read everything myself.

What a good patch looks like

• Small change in current style, no rewrites for beauty
• No new dependencies, no new config mechanisms, no new IPC or protocols
• It builds with zero warnings (cc -std=c11 -Wall -Wextra), warnings itch
• Prove it: luac5.4 -p example/config.lua plus a headless run with socket up and zero config errors
• New behavior needs a live check or an honest NOT VERIFIED line

---

Related

Lineage

Project	Link
swindle	github.com/kantiankant/swindle
dwl	codeberg.org/dwl/dwl

Specifications

Spec	Link
wlroots	gitlab.freedesktop.org/wlroots/wlroots
Wayland	wayland.freedesktop.org
xkbcommon	xkbcommon.org
Lua 5.4	lua.org/manual/5.4

---

License

GPL-3.0, see LICENSE plus attributions in licenses/
